Triangular sail? Maanta has the design solution!
The triangular shade sail is a good option for covering any type of outdoor area: gardens, terraces, attics, outdoor spaces of restaurants or clubs. It blends in perfectly with any type of building thanks to its modern yet sober look. Its form gives it dynamism and elegance.
Thanks to the triangular shape of this product, it is possible to create magnificent combinations of sails to achieve a more eye-catching effect. By overlapping several sails, even of different shapes, you can create optimal visual comfort, suitable for all requirements. Read on below to see what combinations are possible!
Solaria +Plus Waterproof
Solaria +Plus Breathable
The evolution of our best sail with radial cut
Solaria Waterproof
Our best radial cut shade sail
Solaria Breathable
Our best radial cut shade sail
Solaria Furl Waterproof Roll-Up
Our best retractable, radial-cut furling sun shade sail
Solaria Furl Breathable Roll-Up
Our best retractable, radial-cut sun shade sail
Solaria +Plus Furl Breathable
The evolution of our best radial cut furling sail
Solaria +Plus Furl Waterproof
The evolution of our best radial-cut furling sail
EZ Breez Waterproof
The first patented entry level shade sail
EZ Breez Breathable
The first patented entry level breathable sail
Bugna
Shade sail with grommets
Maistra
The retractable designer aluminum canopy / umbrella
Fabric samples
Saill and Solaria sail fabrics
Saill waterproof
high quality shade sail
Saill breathable
high quality shade sail
Insights
How to install a triangular sail
In order to install a triangular shade sail in an excellent manner, it is necessary to provide three fixing points for the corners of the sail. At Maanta we offer two types of fixing: to the wall or by installing a pole.
There are various systems depending on taste and space:
- 3 wall fixing points
- 2 wall fixing points and 1 pole with ground base
- 1 wall fixing point and 2 poles with ground base
- 3 fixing points on poles with ground base
Click here for our wall fixings and poles for shade sails.
Guide to outdoor triangle sun shade models
The triangular sail shades are available in 3 models: EasyShade, Saill or Solaria.
Each of these models is available in either breathable or waterproof fabric, find out the differences with the fabric guide.
- EasyShade: is an entry level sail with an excellent value for money, UPF30+, they have strong sealed seams and side straps around the entire perimeter;
- Saill: they are Made in Italy sails, with cross-cut stripes and digital and automatic stitching, they have top quality materials, multilayer reinforcement, wind resistance up to 50 km/h, reach 36 square metres of coverage, 3-year warranty
- Solaria: are Made in Italy sails, with radial cut, which allows greater distribution of tension, structural strength, durability, better wind resistance, digital and automatic stitching, top quality components, multi-layer reinforcements, wind resistance up to 62 km/h, reach 42 m2 of coverage, 4 year warranty
EasyShade, Saill, Solaria and fabrics: How to choose?
All our shade sails are available in two types of fabric: waterproof (Whathertech) or breathable (HDPE or MESHNET).
The EasyShade model is available in 160g polyester fabric for the waterproof sails and in 180g polyethylene for the breathable sails (HDPE).
While the Saill and Solaria models are available in 270g Purishade® polypropylene fabric for waterproof sails and 320g Meshnet for breathable sails.
The waterproof fabrics are very water-resistant and also provide a perfect shaded area. Purishade®'s polypropylene is a cool, mould-resistant fabric with the lowest environmental impact index. The only disadvantage of polyester is that it can form a cape effect under the sail and is more prone to tearing and stress in wind and storm.
Breathable fabrics have a higher grammage and are very resistant to wind and bad weather, thanks to the wider mesh they do not create a cape effect under the sail and do not accumulate any air or water sacks.
The complete guide to choosing fabrics can be found here.
The measurements of our equal-sided triangles
For the EasyShade model the standard sizes available are: 3.6x3.6x3.6m; 4x4x4m; 5x5x5m; 6x6x6m
For the Saill model the standard sizes available are: 5x5x5m; 6x6x6m
For the Solaria model the standard sizes available are: 5x5x5m; 6x6x6m; 7x7x7m
Custom sizes are possible! Go to the online configurator.
Measurements of our right triangles
Right angle shade sails are also very popular. This shape allows it to adapt perfectly to scenarios with 2 perpendicular walls of the house.
For the EasyShade model the standard sizes available are: 4x4x5.66m; 5x5x7.07m
For the Saill model the standard sizes available are: 5x5x7.07m
For the Solaria model the standard sizes available are: 5x5x7.07m
Also available custom-made directly from our configurator!
Can I combine two triangle shade sails to form a square or a rectangle?
Of course! This combination is one of the most preferred by our customers as it allows you to create a dynamic and sophisticated coverage. By installing two triangular sails at the same two fixing points, shapes such as squares or rectangles can be created.
Be aware, however, of the possibility of a "gap" in the centre, due to the concavity of the sails. If you wish to obtain total coverage, we suggest creating an overlap of the fabrics in order to protect the whole area underneath. This is also the best solution if you want to cover a very large area, which is not possible with a single sail.
Strengths
Take advantage of the triangle shape to create partial coverage of your space. Thanks to the special configuration it is possible to shield the sun only partially in order to create more fluidity with the outside space.
Disadvantages
If the shade created by the triangular sail is not enough for your space, you can opt for a combination of several sails or choose other formats, such as square, rectangle, trapezoid.
WATERPROOF MODELS COMPARISON TABLE
EZ Breez | Solaria | Solaria +Plus | |
---|---|---|---|
Fabric cut | Cross cut (banded) | Radial | Radial +Plus |
Corners | Reinforced 2 layers | Reinforced 5 layers | Reinforced 9 layers |
Available types | Fixed | Fixed, Furl Roller Shutter, Lean Wall Profile | Fixed, Furl Roller Shutter, Lean Wall Profile |
Fabric type | Coated Polyester Fabric | Purishade® Polypropylene | Purishade® Polypropylene |
Available colors | 6 colors | 5 colors | 5 colors |
Seam | Zigzag | Zigzag with triple stitch | Zigzag with triple stitch |
Fabric weight | 220 gsm | 270 gsm | 270 gsm |
Color Persistence | |||
Waterproof | Yes | Yes | Yes |
Seam sealed | Yes | Yes | Yes |
Wind resistance | Up to 30 km/h | Up to 55 km/h | Up to 75 km/h |
Resistance to gusts | Up to 30 km/h | Up to 65 km/h | Up to 90 km/h |
Tear/hail resistance | |||
Water column resistance | 100 mm | 375 mm | 375 mm |
Perceived freshness | |||
Resistance to mildew | |||
Resistance to abrasion | |||
Tension uniformity | |||
Water runoff | 90% | 100% | 100% |
Eco-friendliness | |||
Customized availability | No | Yes | Yes |
Years warranty | 2 | 4 | 4 |
EZ Breez Datasheet | Solaria Datasheet | Solaria +Plus Datasheet |
BREATHABLE MODELS COMPARISON TABLE
EZ Breez | Solaria | Solaria +Plus | |
---|---|---|---|
Fabric cut | Cross cut (banded) | Radial | Radial +Plus |
Corners | Reinforced 1 layer | Reinforced 5 layers | Reinforced 9 layers |
Available types | Fixed | Fixed, Furl, Lean wall profile | Fixed, Furl, Lean wall profile |
Fabric type | HDPE Polyethylene | Meshnet® Virgin HDPE Polyethylene | Meshnet® Virgin HDPE Polyethylene |
Fabric weight | 285 gsm | 320 gsm | 320 gsm |
UV blocking | 96% | 96% | |
Available colors | 4 colors | 5 colors | 7 colors |
Seam | Zigzag | Zigzag with triple stitch | Zigzag with triple stitch |
Color Persistence | |||
Waterproof | No | No | No |
Wind Resistance | Up to 40 Km/h | Up to 60 Km/h | Up to 80 Km/h |
Resistance to gusts | Up to 70 Km/h | Up to 95 Km/h | |
Tear/hail resistance | |||
Perceived freshness | |||
Resistance to mildew | |||
Resistance to abrasion | |||
Tension uniformity | |||
Eco-friendliness | |||
Customized availability | No | Yes | Yes |
Years warranty | 2 | 4 | 4 |
EZ Breez Datasheet | Solaria Datasheet | Solaria +Plus Datasheet |
FAQ
Thanks to our convenient online configurator you can create and order your custom-made sail in a few simple steps.
All you have to do is take the measurements of the area to be covered, enter them into the configurator and choose the fabric and type of seam.
In just a few seconds the system will provide you with a precise quote.
If you are undecided about the colours of our fabrics, you can receive our fabric samples at home, including the 4 different colours of Purishade® fabric (for waterproof sails available in the colours White, Ivory, Cloud, Beige) and the 4 different colours of Meshnet 320 fabric (for breathable sails available in the colours Ivory, Beige, Cloud, Graphite) plus a 10€ discount voucher for your next purchase of a Solaria or Saill shade.
The expected delivery date is indicated immediately, both in the product section and during the order confirmation.
However, the delivery time for a triangle sun shade can change depending on the season. After receiving the order, our technical team designs the sail using digital programmes.
The technical drawing linked to the order is then put into the production plan (digital cutting, hand stitching, final quality control), packed and then shipped.
We recommend first designing the fixing system. Place or design the position of wall plates or support poles. This way you can easily take measurements between anchor points.
Our configurator will show you the measurements you need to design the sail (lengths of the sides and/or diagonals). It is essential to provide the necessary space for the fixing means.
Always plan for at least 35 cm between each corner of the sail and its anchoring point. If you are not sure, choose the option "I will provide the distance to the fixing points".
The sail will be calculated automatically in our configurator. The system automatically chooses the correct size for your sail.
The drainage point is the angle to be chosen in any custom-made sail to allow perfect drainage of water in case of rain, as well as in case of condensation that may form on the underside during periods of high humidity.
In this way, water will always flow towards a certain angle of the sail, thanks to the "tile principle", and water will always be able to drain away.
